Since I [changed the Rings project to be an isometric tower defense](/blog/a-big-turn-in-the-rings-project) , I've been having some problems with the 2D representation of things in this perspective. Why, you may ask? The thing is that the isometric view is exactly what I described—a representation of the actual 2D top-down game. However, when I started this project, I wasn't considering that isometric would entail more than just a different way of drawing. Unfortunately, this oversight has led to some coding issues

# The beginning of the problem

When I first started making changes to the project's categories, I was only thinking about the mouse interaction with the isometric tiles. So, I followed a tutorial to accomplish this and continued from there.

Initially, my focus was primarily on how the mouse was interacting with the units on those tiles. I considered aspects such as hover detection and the potential problems that could arise, such as:

- What if the unit is taller than the tile? How can I prevent the selection from going to the wrong tile?
  ![test](behind-tower-selection.webp)
- What if there's a unit positioned behind another unit? How can I select the intended one?
  ![second](unselectable-tile.webp)

These small problems overshadowed the magnitude of the challenge I was facing.

# The realization

I implemented the unit placement and deletion functionalities, created a simple targeting system, and developed a Bullet class. I was about to start working on the actual defense mechanisms that the towers would perform.

Next, I began coding the system responsible for firing at the target as soon as it entered the unit's range. However, I encountered a roadblock and couldn't figure out a simple solution. On the surface, it was just a matter of calculating the intersection of circles. Yet, inexplicably, I couldn't make it work.

To create the range ellipse, I used an ellipse since the game had an isometric view. Technically, it wasn't a perfect circle. However, I found myself attempting to calculate ellipse intersections using 2D positions, needlessly complicating everything.

Eventually, when I stopped working on the project, I started reflecting on the issue.

> The state of enemy detection
> ![current-colision](current-colision.webp)

If I have the 2D grid of every tile and the tile position of every unit, why not calculate the range intersection in the top-down view of the tiles and then convert this result later before rendering?

That's precisely what I have started implementing this week as I return to the project after almost a year.

# Let's start by looking at things

Something that has always facilitated this kind of implementation for me is the visualization of the context. Whether it's a simple `print` statement to display the behavior of a variable or even coloring a `<div>` to understand how it affects the entire website's layout (yes, that has happened).

That's why I've decided to develop a top-down debug view for the game. This will not only facilitate the new implementation but also aid in understanding future features and identifying bugs. It's currently a work in progress.

The debug view has helped me realize the issue with my current approach to the isometric perspective. I was constantly thinking in isometric terms instead of considering the underlying 2D representation. In reality, the isometric view doesn't actually exist!

I encountered significant difficulties in determining the actual 2D positions of the elements, to the extent that I had to revisit sections of the code to understand how things were placed, drawn, and recognized in the game.

Questions like how the mouse determines the tile it is hovering over, how the tiles are stored to create a grid, and how to convert coordinates into tile positions (matrix positions) prompted me to reconsider a substantial portion of our rendering and computing pipeline.

> The complexity of the current pipeline far outweighs the simplicity it is meant to achieve."

# Get a step back and rethink the pipeline

Basically, my current plan is to refactor all the isometric-related code to create a simpler pipeline that the entire game can follow, and one that can be easily modified if necessary.

I will store the tile position of every entity and transform it to isometric coordinates during rendering.

> The current debug view ![current-debugger](current-debugger.webp)

Another issue I encountered is the abundance of variables that complicate matters. For instance:

Should the `Unit` class store both `screen_position` and `tile_position`? If I only need the screen position when necessary, wouldn't it be better to transform it dynamically? I don't believe it would require excessive computing power.

```python
class Unit(Entity):
	tile_position: Vector
	screen_position: Vector`
```

---



Why am I passing the game to the `UnitManager` instance? And why did I name the parameter `window`?

```python
class UnitManager:
	def __init__(self, window):
 		self.selected_unit = None
		self.window = window

class Game:
	def __init__(self):
		self.unit_manager = UnitManager(self)
```

As I rewrite this _Top-down to Isometric Logic_, I'm likely to come across more nonsensical code here and there. But for now, that's the plan.

Now, I'll proceed to complete my top-down visualization as I once again refactor this code. Take care not to disrupt your own pipeline in your project!

The Problem with Isometric Graphics


In the [last post](/blog/the-refactoring-process-in-rings-code) I presented you the Rings project, a repository where I (Renato) started implementing some basic systems that I would use in game development in the future. First, as I said in the last post, the idea was to make a rogue-like top-down shooter, but some days ago, I decided that to keep it simple and with the least amount of complexity, Rings should be a Tower Defense game.

# The complexity thing
When you start to think about how to manage multiple abilities that interfere with one another; hundreds of bullets can collide, bounce, go back and pass through stuff. You start to think that Python and Pygame maybe is not the right choice for the job, and starting everything from zero with a new language is kind of a hard decision as well.

But now imagine a game with static units, fixed targets, simple upgrades, and a stateless game loop, you can accept Python as a decent tool for the job.

But, to add more dynamics to the game, I decided to implement an isometric style. The main idea was to bring the semi-3D perspective and the strategi feeling that this kind of graphics brings to games. The first games of **Age of Empires** used those graphics for example. And I think that this is a way to make things more challenging.

![unit_selection](age-of-empires.webp)

# New inspirations and the main idea
Since the rogue-like games exploded in the last few years, the idea is to go against this, for more strategic gameplay. Recently I played [Rogue Tower](https://store.steampowered.com/app/1843760/Rogue_Tower/), rogue-like tower-defense with voxel graphics, its a pretty fun game, but I get bored with it after the first plays, the range of builds is not diverse enough that you want to experiment with other types of stats and machines.

A game that does this part very well is [ Despot's Game: Dystopian Army Builder](https://store.steampowered.com/app/1227280/Despots_Game_Dystopian_Army_Builder/), which goes for an auto-battle (TFT vibes) with class combinations and power-ups.

So, the idea is to mess up with those concepts in a [Bloons TD 6](https://www.google.com/url?sa=t&rct=j&q=&esrc=s&source=web&cd=&cad=rja&uact=8&ved=2ahUKEwjH36jBtbX6AhV7s5UCHYc0ALMQFnoECAsQAQ&url=https%3A%2F%2Fstore.steampowered.com%2Fapp%2F960090%2FBloons_TD_6%2F&usg=AOvVaw1Q3-OUytRLn3tVpRT1PUBm) style as well. With a variety of units each one with its purpose and class, so you can play with those kinds of combinations.

Since I'm a noobie game developer, my ideas and implementations probably will go pretty badly, but the idea is to experiment with everything before making a serious game.


# The Game so far
It's important to say that we don't have any style concept formed so far, don't have gameplay and the base of Pygame start code continues there. For the first interactions of the game, I focused on doing the isometric stuff (that is harder than it looks). Then I created an `UnitManager` to take care of the unit placement and delete.

To make the Unit selection I needed to work better on detecting which Tile and which Unit I was hovering with the mouse, It's kind of tricky but it does the job.
![unit_selection](unit_selection.webp)

I still need to improve the isometric-to-plane logic, because now I'm stuck on the code to detect if an enemy enters a unit range, and I cannot use the isometric position straight ahead, I need to make some kind of conversion. I need to calculate those collisions in the flat plane and then, only transform to isometric when needed (to draw and calculate mouse collision with units).

I made a simple shoot system just to try it out, but need to fix those collisions before showing anything.

# Some problems
Finally, as things progress it get's harder to develop some stuf, that's why we should build things different. But at the same time we need to make things work before refactoring it. Another thing that I'm facing is unit testing problems.

What, where and how to test thing in a video-game code? Should you test it with all things turned on? (like graphics) Or should you just test the intern things like sub-functions? Given that things change brutly during early development, those test can start to requiring more work then the real code, and it's kind ok to do that, since those tests hold your software together and protected from future mistakes.

Anyways, I need to start testing as soon as possible. I Will write abou testing when I make it.

A Big Turn in The Rings Project



Hi There! I would like to introduce to you one of my (and Back to Pixels) project **Rings**. And perhaps show some big refactorings
 that I did some days ago.

# Presenting Rings
Rings is a pygame video-game project that initially was inspired by [Enter the Gungeon](https://enterthegungeon.com) and [Nuclear Throne](https://nuclearthrone.com) (even the sprite animation test was done using its sprites). But with time (and some studies) I realized that this scope was too big for my first game, and by the time I was pretty into [Vampire Survivors](https://store.steampowered.com/app/1794680/Vampire_Survivors/), so I decided to redirect Rings to be a "stand-still" rogue-like game. Aiming to try some video-game software architecture and push to the limits that python can do as a game development language!

> The name rings was referring to the upgrades in the game, that would be rings that you could use, a maximum of 10.

But a complete game is still a big scope for someone that studies and has a full-time job. So, my current idea is to develop each feature of a simple game development framework just to experiment with some module architectures.

And here today I will show you what was *Rings* was before and after some cool structural changes that I made based on some simple things that I've learned recently.

# How It Was and Where it is Going
Since I'm just developing feature to feature, my architecture thing was not that important, so I kept the code struct as the simple pygame tutorial would give you, which is, extremely bad, but with the simple *check-events*, *update entities*, *render entities* order.

But after seeing some [DaFluffyPotato](https://www.youtube.com/c/DaFluffyPotato) live streams I start to recognize a pattern in his code. He put everything into a *Game* class, and passes this game class to everyone inside it (this part is pretty dangerous but ok), and inside this class, he has a *world* attribute (of the class World) and an *Input* attribute (of the class Input) and so on for every major thing in his game. He also had some classic structs such as a list of *entities* and a list of projectiles.

Anyways, this architecture can help a lot such in debugging (because um can tear apart things easily) and in modularity.

So that's where I aimed to when refactoring Rings for (almost) the first time.

# Some Bad Code
Here I will show you how the code was (it is a little bit longer, so maybe I will change it in the future)


```python
configs = json.load(open('config.json'))

pygame.init()
pygame.mixer.pre_init(44100, -16, 2, 512)
pygame.mixer.set_num_channels(32)
pygame.display.set_caption("Rings")
pygame.mouse.set_visible(False)

FONT = pygame.font.Font("res/Pixellari.ttf", 22)

global debugging
game_time = 0
base_screen_size = configs['resolution']
screen = pygame.display.set_mode(
	(base_screen_size[0],base_screen_size[1]),0,32
)
display = pygame.Surface((300,200))
clock = pygame.time.Clock()
screen_real_size = display.get_size()
camera = Vector(0,0)

player = Player(Vector(10,10))
player.load_animations()

TILE_SIZE = 20

game_map = [...]

cursor_img = pygame.transform.scale(
	pygame.image.load('res/mouse.png').convert(), (44, 44)
)

cursor_img.set_colorkey((255, 0, 0))

camera_speed = 20
debugging = True
running = True

while running:

	for event in pygame.event.get():
		check_events(event,player)

	mx, my = pygame.mouse.get_pos()

	true_mx = mx
	true_my = my

	mx -= (screen.get_width() - base_screen_size[0]) // 3
	my -= (screen.get_height() - base_screen_size[1]) // 3
	mx /= base_screen_size[0] / display.get_width()
	my /= base_screen_size[1] / display.get_height()

	camera.x = player.position.x + 7 - screen_real_size[0] /2 # the +7 is half of the size of the player, to certralyze
	camera.y = player.position.y + 7 - screen_real_size[1] /2

	player.is_not_walking = not player.is_moving_right and not 		player.is_moving_up and not player.is_moving_down and not player.is_moving_left


	scroll = camera
	scroll.x = int(scroll.x)
	scroll.y = int(scroll.y)

	display.fill((30,30,30))

	collision_tiles = []
	tile_rects =[]

	y = 0

	for row in game_map:

	x= 0

	for tile in row:
		#<big tiles logic and draw>
		for t in row:
			#<more logic and draw world stuff>

	player.update(mx, collision_tiles,camera)
	player.draw(display,debugging)

	screen.blit(pygame.transform.scale(display, base_screen_size),

	((screen.get_width() - base_screen_size[0]) // 2,

	(screen.get_height() - base_screen_size[1]) // 2))

	screen.blit(cursor_img, (true_mx // 3 * 3 + 1, true_my // 3 * 3 + 1))

	if debugging:

		utils.draw_text(FONT, "FPS: " + str(int(clock.get_fps())), screen, (10,10))

	pygame.display.update()
	clock.tick(60)
```

> I removed some unnecessary parts

# Some less-bad code
```python
class Game:
	_entities: list
	game_time: int
	player: Player
	window: Window
	world: World
	mouse: Mouse
	camera: Camera

	def __init__(self):
		configs = json.load(open("config.json"))
		self.window = Window(configs)
		self.mouse = Mouse(self.window)
		self.world = World()
		self.player = Player(self)
		self.player.load_animations()
		self.camera = Camera(
				self.player,
				self.window.screen_real_size
		)


		self._entities = []
		self._entities.append(self.player)
		self.running = True
		self.clock = pygame.time.Clock()
		self.FONT = pygame.font.Font("res/Pixellari.ttf", 22)


	def update(self):
		self.world.update()
		self.mouse.update()
		self.camera.update()
		for entitiy in self._entities:
			entitiy.update()

		pygame.display.update()
		self.clock.tick(60)

	def draw(self):
		self.window.display.fill((30, 30, 30))
		self.world.draw(self.window.display, self.camera.position)

		for entitiy in self._entities:
			entitiy.draw(self.window.display, self.camera.position)


		self.window.blit_displays()
		self.mouse.draw(self.window.screen)

	def run(self):
		while self.running:
			self.check_events()
			self.update()
			self.draw()

game = Game().run()
```

Even with this "better" code, there are always things to improve everywhere. Such as an Input class to handle all the input commands and logic (that I hid in this example), or some particles and sound managers (that I didn't implement yet).

As Uncle Bob says in "Clean Architecture":

> Good (clean and well architectured) code, should look like a well-written poem

The new rings architecture looks like some Ok poem, but I think it could be better, mainly in the *Player* class (the animation system is kind of messed up). In the end, all I did was hide things properly and reallocate them where they should be.

All the world logic and drawing are inside the *World* class, for example, and the same thing applies to all the other pieces of the game. It's clear that I don't have much to organize, but it was a good starting point to do all these refactorings.


# What Rings have until now?
Rings started as an experiment, just me trying to implement some cool game-development features. So, the project doesn't have much, just some split, badly implemented simple features, like particles, animations, collisions, and sparks (that I just copied from DaFlufy). But those simple things that I have will be re-write and documented here in the future.

For now, the game looks something like this:

![game-screen-shot](game-screen-shot.webp)

> I used the Nuclear Throne animation to test some stuff ;)


# Conclusion

As I said, Rings are only the start, and I pretend to turn it into a simple rogue-like game, and that's some of the things I will bring her to the game-studio blog.

I will bring some cool implementations and mainly focus on game-design architecture.

Hope you like it and Thanks for reading! You can follow all **Rings** articles in [tag/rings](/blog/tag/rings)

You can check out this project on my [RenatoCesraF/Rings](https://github.com/RenatoCesarF/Rings)

The Refactoring process in Rings code




I just finished the implementation of the default images that appear on posts that don't have a cover. It was something that wants to implement because those old flat colors were very ugly.

![posts-exemple](posts-exemple.webp)

The logic is to have those default images saved locally and just change the `cover_image` URL to a default one when the post doesn't have a `cover_image` defined. We can choose default cover images as well using **number**.

# How To make Good-Looking Cover Images
Yes! Those images are pretty cool. I found an online generator of section-transition images to be used in websites, but the images are so cool that can be used anywhere (you can check out the [generator here](https://app.haikei.app/)).

![generator-site](generator-site.webp)

So I changed the colors and play a little bit with the configuration in some generation options and ended up with this ones:

![default-image-1](default-image-1.webp)

---

![default-image-2](default-image-2.webp)

---

![default-image-3](default-image-3.webp)

---

![default-image-4](default-image-4.webp)

---

# How The System Works

The system is very simple. We just verify if the `cover_image` variable is a valid image, or if it's of the type *Number*. If the image isn't valid or is a number we choose one of the four default images and use its URL instead. Let's see:

# How We Store Posts Images

Before understanding how the default images work, you need to understand how we store our post-images in the first place. All the website logic, programming, design was made by me ([Renato](/team/renato)). And I do not have sure that this is the best architecture option to store posts images, but is the one that most fits my case. Maybe in the future, it changes (I hope not). But for now, it is what it is.

We have a **posts** folder in the root directory. inside this folder, there is every single post written in a `.md` format. The name of each post is its name in lower keys separated by a dash/trace '-'. For example, this post file name is `default-images-and-our-images-architecture`. This name serves as **slug**/ID for the post. Now inside our `public/images` folder, we have another **posts** folder, this one has one folder for each post written, the name of those subfolders are the same as the post that it belongs to. Inside those subfolders, we store all the images used in each post.

![folder-organization](folder-organization.webp)

I think this is a good approach to storing multiple blog images. It would be a terrible solution to just throw every single image inside the same folder, and not separate it by post. How would you find an old image inside it? How would you manage thousands and thousands of images when the website grows?

Another thing is the dash/trace ('-') nomenclature chosen. I know that CammelCase is good when you are coding, but it's good when you are using the code font, and not a file / OS font. It's terrible to read it in almost all common fonts. So the dash is a good choice. And why not an underscore ('_')? To tell the truth, is simpler than it looks: it takes more work to type. Instead of using `shift + '-'` to write every simple space in the word, just use the dash. In the end, it's like a space-bar on the top of the keyboard :)

---

In this way, we have an organized way to store all our images knowing where each one is always.


# And The Default Images?

Each *default image* is saved in a `default-images` folder, inside `images/posts` as a number (1 to 4) in `webp` format (because of performance).

Our "choose image function" is called `getCoverImage()`.

It receives a **slug** And a **image_name**. This *image_name* is set in the header of the `.md` file. It just contains the name of the image that will be on the cover. Why just the name? Because we already have the **slug** of the post (that is, the *name* of the post folder where all the images are). So we can get any image just using `images/posts/{slug}/{image_name}.webp`.

> I just realized that I can use this same strategy to get every single image inside the post. So instead of declaring it `images/posts/default-images-and-how-we-store-images/image-name.webp` we can just use `ìmages-name.webp` for now on!

Anyway, The first thing we do in our `getCoverImage()` is to create the return variable and check if the image exists or if the type of the variable is a number.

```js
var coverImage;

if(!isImageCoverValid(slug, image_name) || typeof(image_name) === "number"){
	 var defaultImageIndex = image_name || Math.floor(Math.random() * 4) + 1;
	 coverImage = `/images/posts/default-images/${defaultImageIndex}.webp`;
	 return coverImage;
}
```

if it's a number, that means that the author wants to choose one of the default images. So just set the `defaultImageIndex` as this number. But if it is not valid (is null or starts with "HTTP" or is not in the post folder) choose a random number to get a random default image in the next line. So the cover image source string is made, and the value returned to the post.cover_image.

Now, if the image is valid, we just create the source path using the variables (slug and image_name) and return it:

```js
coverImage = `/images/posts/${slug}/${image_name}.webp`;
return coverImage;
```

Look how the **isImageCoverValid()** works inside:

```js
const isImageCoverValid = (slug: string, image_name: any) => {
	const isImageTextValid: boolean = (
		typeof(image_name) === "string" &&
		!image_name.toString.startsWith('https')
	)

	if(image_name === null || !isImageTextValid ){
		return false;
	}

	var imageExistInFolder = false;
	const images: string[] = readdirSync(join(`public/images/posts/${slug}`));

	for(let image of images) {
		 if(image.replace('.webp', '') === image_name){
			 imageExistInFolder = true;
			 break;
		 }
	}

	return imageExistInFolder;
}
```

We check if is a text and if has *HTTP* (we do not allow other cloud images). If is not null and is a valid text we create a variable `imageExistInFolder` and start to search for the image inside the post folder. If the image appears we *break* the loop and return that the image is valid. So doesn't need to use a default image.


certainly

Of course, there is room for improvement all over it, (like creating the images with Python instead of using HTML tag to make the post date in the middle). But for now, it's this.

Anyways, this was the best post written until now. So I hope you enjoy it!
